Large Format Fiber Laser Marking Machine for Large Metal Plates
✓ CE FDA Certified ✓ 24-Month Warranty ✓ OEM & ODM
✓ Lifetime Technical Support ✓ Global Shipping ✓ Free Sample Test
Do you need to laser mark a large metal plate that will not fit a conventional galvo marker?
The HITEC HTJ-6090 Pro is a large format fiber laser marking machine designed for oversized metal plates, stainless steel sheets, elevator panels, industrial nameplates and large components.
Instead of relying on a small fixed galvo marking field, the system combines a high-speed galvo scanning head with a motorized XY gantry to extend the processing area.
Available working areas include 2′ × 2′ (24″ × 24″, 600 × 600 mm), 2′ × 3′ (24″ × 36″, 600 × 900 mm), 4.3′ × 3′ (51″ × 35″, 1300 × 900 mm), 4′ × 4′ (47″ × 47″, 1200 × 1200 mm), 4.3′ × 8.2′ (51″ × 98″, 1300 × 2500 mm), with custom configurations available for specific workpieces.
When a Standard Galvo Laser Is Too Small
A conventional fiber laser marker may provide excellent speed and precision, but its optical marking field is limited by the field lens.
For small components, this is rarely a problem.
For large metal plates, however, manufacturers may face:
❎ Limited effective marking area |
❎ Repositioning of large workpieces |
❎ Multiple marking fields |
❎ Stitching and alignment concerns |
❎ Additional setup time |
❎ Difficulty processing oversized panels |
The HTJ-6090 Pro was developed for exactly this type of application. The workpiece remains positioned on the machine table while the laser system moves across the required processing area — extending the effective marking field well beyond what a fixed galvo lens can cover.
Large workpiece → Large working area → Motorized XY movement
Watch the Gantry Cover a Full Metal Plate
Built for Large Metal Marking Applications
Large Format Laser Marking for Stainless Steel
Suitable for large stainless steel sheets and fabricated metal components.
Elevator Panel Laser Marking
Large stainless steel elevator panels often exceed the practical marking area of a conventional desktop fiber laser. The HTJ-6090 platform provides a large mechanical working envelope built for this exact application.
Laser Marking Machine for Large Metal Nameplates
For industrial equipment manufacturers producing equipment nameplates, asset plates, specification plates, serial number plates, QR code plates and brand logos — the large table can also be used to arrange multiple smaller plates in one setup.
Laser Marking for Large Industrial Parts
Mark permanent identification, serial numbers, logos and traceability codes directly onto metal surfaces used in metal fabrication, machinery manufacturing, automotive, industrial equipment, tooling and electrical equipment.
Large Format Marking Gallery
Explore the Large Format Marking Gallery from HITEC Laser, featuring real-world applications such as black and white laser marking on stainless steel and aluminum, large-format elevator panel marking, flying laser marking, moving marking, nameplate marking, deep engraving, and batch marking of large metal workpieces. These laser marking applications demonstrate precise, consistent, and efficient processing across a wide range of industrial metal products.
Large Format Gantry Laser vs Conventional Galvo Laser
| Conventional Galvo Marker | HITEC Large Format System | |
|---|---|---|
| Small parts | Excellent | Excellent |
| Large metal plates | Limited | Designed for large workpieces |
| Optical field | Lens-dependent | Extended by XY movement |
| Large panels | Difficult | Suitable |
| Multiple nameplates | Possible | Efficient batch layout |
| Manual repositioning | Often required | Reduced |
| Oversized components | Limited | Designed for industrial applications |
| Custom working area | Limited | Configurable |
What Can You Mark With a 6090 Large Format Laser?
| Application | Typical Workpiece |
|---|---|
| Large metal plate marking | Stainless steel / aluminum sheets |
| Elevator panel marking | Stainless steel elevator doors |
| Metal nameplate marking | Industrial identification plates |
| Large logo engraving | Metal signs & equipment |
| Deep metal engraving | Steel / stainless steel / aluminum |
| Industrial traceability | Serial numbers / QR codes |
| Batch marking | Multiple metal plates |
| Decorative engraving | Large metal panels |
A galvo laser is not automatically inferior. For small parts, it can be the better choice. The advantage of a gantry system appears when the workpiece itself becomes larger than the practical optical marking field.
HTJ-6090D Configuration
| Laser Type | Fiber Laser |
| Laser Power | 50W – 500W |
| Laser Source | JPT / IPG / Raycus |
| Wavelength | 1064 nm |
| Working Area | 2′ × 2′ (24″ × 24″, 600 × 600 mm) to 4.3′ × 8.2′ (51″ × 98″, 1300 × 2500 mm) |
| Motion | Motorized XY Gantry |
| Software | EZCAD3 / ZEUS |
| Auto Focus | Optional |
| Rotary Axis | Optional |
| Application | Marking / Engraving / Deep Engraving |
2′ × 2′ (24″ × 24″) ≈600 × 600 mm | 2′ × 3′ (24″ × 36″) ≈600 × 900 mm | 4.3′ × 3′ (51″ × 35″) ≈1300 × 900 mm | 4′ × 4′ (47″ × 47″) ≈1200 × 1200 mm | 4.3′ × 8.2′ (51″ × 98″) ≈1300 × 2500 mm |
Why Choose the HITEC Large Format System
Extended Working Area
Motorized XY gantry extends the effective marking field well beyond a fixed galvo lens.
Configurable Power
50W to 500W fiber laser sources for marking through to deep engraving.
Efficient Batch Layout
Arrange multiple nameplates or smaller components on one large table.
Configurable Working Area
Standard sizes from 600×600 mm up to 1300×2500 mm, plus custom configurations.
Frequently Asked Questions
What is a large format laser marking machine?
A large format laser marking machine combines a galvo scanning head with a motorized XY gantry to extend the effective marking area beyond a standard fixed optical field, allowing it to process oversized metal plates and components.
Can a laser mark a large stainless steel sheet?
Yes. A large format fiber laser marking machine with an XY gantry can mark large stainless steel sheets, including sizes that exceed a conventional desktop marker’s field.
What is the difference between a galvo and gantry laser marker?
A galvo laser marker processes within a fixed optical field defined by its lens. A gantry laser marking machine adds motorized XY movement so the marking head can travel across a much larger working area.
Can the HITEC 6090 mark elevator panels?
Yes. The large table can be used to arrange multiple smaller plates, such as nameplates, in a single setup for efficient batch marking.
Can a 6090 laser mark multiple metal plates at once?
Yes. The large table can be used to arrange multiple smaller plates, such as nameplates, in a single setup for efficient batch marking.
What size metal plate can a 6090 laser mark?
Standard working areas range from 600×600 mm up to 1300×2500 mm, with custom configurations available for specific workpieces.
Can a fiber laser engrave stainless steel deeply?
Yes. Higher-power fiber laser configurations, such as 100W, 200W, 300W or 500W, can be selected for deep engraving on stainless steel, aluminum, brass and other metals.
Does a large format laser require stitching?
Because the gantry physically moves the marking head across the workpiece, a large format system is designed to reduce the repositioning and stitching typically required by a fixed-field galvo marker on oversized parts.
What working area should I choose for large metal plates?
The right working area depends on your largest workpiece dimension and whether you plan to batch multiple smaller plates in one setup. Available sizes include 600×600 mm, 600×900 mm, 1300×900 mm, 1200×1200 mm and 1300×2500 mm.
Is a 100W, 200W or 300W fiber laser better for deep engraving?
Required depth, material and cycle time determine the appropriate power level. A sample test provides a more reliable basis for selecting power than wattage alone.
Can the working area be customized?
Yes. In addition to standard working areas, custom configurations are available for specific workpiece dimensions.
Get the Right Working Area for Your Plate Size
Send your plate dimensions, material and required marking. HITEC engineers will recommend the working area, laser power and configuration for your application.
